Summary of Contents for Thermo Scientific 3625A
- Page 1 Thermo Scientific Hi-Temp Programmable Vacuum Oven Operating Manual 107567 Rev. 0 _________________________________________________________________________________ Part of Thermo Fisher Scientific...
- Page 2 Preface Models covered in this manual Catalog numbers Model numbers Voltage 3625A 6250 120V 3625A-1 6251 240V MANUAL NUMBER 107567 (7006250) 3/31/10 Transfer to Marietta (was 107567 2/6/09) ECR/ECN DATE DESCRIPTION Thermo Scientific Programmable Vacuum Oven...
- Page 3 Material in this manual is for information purposes only. The contents and the product it describes are subject to change without notice. Thermo Scientific makes no representations or warranties with respect to this manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising out of or related to the use of this manual.
- Page 4 This product is required to comply with the European Union’s Waste Electrical & Electronic Equipment (WEEE) Directive 2002/96/EC. It is marked with the WEEE symbol. Thermo Scientific has contracted with one or more recycling/disposal companies in each EU Member State European Country, and this product should be disposed of or recycled through them.
- Page 5 We can also provide you with a quotation on our Extended Warranty for your Thermo Scientific products. Whatever Thermo Scientific products you need or use, we will be happy to discuss your applications. If you are experiencing technical problems, working together, we will help you locate the problem and, chances are, correct it yourself...over the telephone without a service...
-
Page 6: Table Of Contents
Electrical Schematic .........7-1 Thermo Scientific... -
Page 8: Introduction
The Vacuum Oven can fulfill practically every need associated with general drying, conditioning, curing, desiccating, and annealing – as well as moisture tests. When compared with conventional ovens, samples dry faster at lower temperatures, and heat-sensitive materials dry safely without degradation problems. Thermo Scientific Programmable Vacuum Oven... -
Page 10: General Specifications
Performance Characteristics Power Requirements: Cat. No. 3625A ..120V, 50/60 Hz, 8.5A Cat. No. 3625A-1 ..240V, 50/60 Hz, 4.2A Power Input: ....1000W max. - Page 11 Section 2 General Specifications Approximate Heat Up Times to Various Temperatures T. Initial T. Final Standard Accelerated 25°C 100°C 75 min. 35 min. 25°C 200°C 95 min. 75 min. 25°C 275°C 120 min. ---------- Programmable Vacuum Oven Thermo Scientific...
-
Page 12: Unpacking
To assure an airtight connection, use thread sealing compound or Teflon sealing tape. Caution Never operate unit with caps in openings. Under certain circumstances, they could clog vacuum and purge lines. Thermo Scientific Programmable Vacuum Oven... - Page 13 Note Vacuum operation to 30” Hg can be obtained easily using a single- stage mechanical pump with a free air capacity of 35 liters per minute. Programmable Vacuum Oven Thermo Scientific...
-
Page 14: Operation
Approximated Heatup Times to T. Initial T. Final Standard Accelerated Various Temperatures 25°C 100°C 75 min. 35 min. 25°C 200°C 95 min. 75 min. 25°C 275°C 120 min. ---------- Thermo Scientific Programmable Vacuum Oven... -
Page 15: Accelerated Heatup Method
3. Example: 100°C setting is approximately position #7. Set dial to position #9 until actual temperature on the thermometer is 80°C. Set the dial to position #7. The oven will stabilize in about half the time compared to a standard run. Programmable Vacuum Oven Thermo Scientific... -
Page 16: Safety Precautions
Do not place volatile items in the chamber. Fumes and spillage from acidic solutions cause corrosion of the stainless steel chamber. Care should be taken to maintain neutral pH at all times. Thermo Scientific Programmable Vacuum Oven... -
Page 18: Maintenance
Replacing the temperature controller or the heating elements requires complete disassembly of the cabinet panels and insulation, and should be Heating Element Repl. done only by qualified personnel. If it should become necessary to replace any of these components, contact Technical Services. Thermo Scientific Programmable Vacuum Oven... -
Page 20: Replacement Parts/ Accessory Items
LL30790 Temperature Controller (120V) LL83372 Temperature Controller (240V) LL88196 Knob, Temp. Controller (PC26B 1) LL32615 Power Switch (S1) LL102627 Door Seal Replacement Kit LL50430 Shelf LL02340 Hose Connector (1/4”) LL98573 Vacuum Grease LL16023 Thermocouple LL102716 Thermo Scientific Programmable Vacuum Oven... - Page 22 Thermo Scientific Programmable Vacuum Oven...
- Page 24 Thermo Scientific 401 Millcreek Road Marietta, Ohio 45750 United States www.thermofisher.com...
