Light guidelines

Use the following guidelines to ensure that there is proper lighting for facial authentication.
• Avoid direct light above or behind the user.
• Place the instrument in a position that minimizes backlight.
• For optimal results, place the instrument between two ceiling lights.

Electrical requirements

CAUTION! Do not unpack or plug in any components until they are configured for the proper
operating voltage by the service representative.
WARNING! For safety, the power outlet for the instrument must be accessible at all times. See
"Instrument dimensions"
the instrument. In case of emergency, you must be able to immediately disconnect the main power
supply to all the equipment. Allow adequate space between the wall and the equipment so that the
power cords can be disconnected in case of emergency.
• Electric receptacle required: Grounding capability required
• Maximum power dissipation: ~417 VA, 371 W (not including computer and monitor)
• Mains AC line voltage tolerances must be up to ±10 percent of nominal voltage
Device
Instrument
Computer (desktop)
Monitor
Computer (laptop)
[1]
If the supplied power fluctuates beyond the rated voltage, a power line regulator may be required. High or low voltages can adversely
affect the electronic components of the instrument.
QuantStudio ™ 6 Pro Real-Time PCR System and QuantStudio
on page 188 for information about the space needed between the wall and
Rated voltage
100–240 ±10% VAC
100-240 ± 10% VAC
100-240 ± 10% VAC
™ 7 Pro Real-Time PCR System User Guide
Appendix A Instrument specifications and layout
Circuit
required frequency
[1]
10 A
10 A
10 A
Electrical requirements
Rated
Rated power
50/60 Hz 960 W
125 VA
50/60 Hz
65 VA
50/60 Hz 90 VA
A
191
