RM0440
Bit 2 CMP3: Compare 3 interrupt flag
Refer to CMP1 description
Bit 1 CMP2: Compare 2 interrupt flag
Refer to CMP1 description
Bit 0 CMP1: Compare 1 interrupt flag
This bit is set by hardware when the timer x counter matches the value programmed in the
compare 1 register.
0: No compare 1 interrupt occurred
1: Compare 1 interrupt occurred
27.5.14 HRTIM timer x interrupt clear register (HRTIM_TIMxICR) (x = A to F)
Address offset: Block A: 0x088
Address offset: Block B: 0x108
Address offset: Block C: 0x188
Address offset: Block D: 0x208
Address offset: Block E: 0x288
Address offset: Block F: 0x308
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
DLYPR RSTx2
Res. RSTC
TC
w w
Bits 31:15 Reserved, must be kept at reset value.
Bit 14 DLYPRTC: Delayed protection flag clear
Writing 1 to this bit clears the DLYPRT flag in HRTIM_TIMxISR register
Bit 13 RSTC: Reset interrupt flag clear
Writing 1 to this bit clears the RST flag in HRTIM_TIMxISR register
Bit 12 RSTx2C: Output 2 reset flag clear
Writing 1 to this bit clears the RSTx2 flag in HRTIM_TIMxISR register
Bit 11 SETx2C: Output 2 set flag clear
Writing 1 to this bit clears the SETx2 flag in HRTIM_TIMxISR register
Bit 10 RSTx1C: Output 1 reset flag clear
Writing 1 to this bit clears the RSTx1 flag in HRTIM_TIMxISR register
Bit 9 SETx1C: Output 1 set flag clear
Writing 1 to this bit clears the SETx1 flag in HRTIM_TIMxISR register
Bit 8 CPT2C: Capture 2 interrupt flag clear
Writing 1 to this bit clears the CPT2 flag in HRTIM_TIMxISR register
28 27 26 25
Res. Res. Res.
12 11 10 9
SET2x RSTx1 SET1x
C C C C
w w w w
24 23 22
Res. Res. Res.
8 7 6
CPT2C CPT1C UPDC
w w w
RM0440 Rev 4
High-resolution timer (HRTIM)
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
Res. REPC CMP4C CMP3C CMP2C CMP1C
w w w w
17 16
Res. Res.
1 0
w w
