ST STM32G4 Series Reference Manual page 1212

Advanced-control timers (TIM1/TIM8/TIM20)
Bit 31 GC5C3: Group channel 5 and channel 3
Note: it is also possible to apply this distortion on combined PWM signals.
Bit 30 GC5C2: Group channel 5 and channel 2
Note: it is also possible to apply this distortion on combined PWM signals.
Bit 29 GC5C1: Group channel 5 and channel 1
Note: it is also possible to apply this distortion on combined PWM signals.
Bits 28:20 Reserved, must be kept at reset value.
Bits 19:0 CCR5[19:0]: Capture/compare 5 value
28.6.22 TIMx capture/compare register 6 (TIMx_CCR6)(x = 1, 8, 20)
Address offset: 0x04C
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
1212/2126
Distortion on channel 3 output:
0: No effect of tim_oc5ref on tim_oc3refc
1: tim_oc3refc is the logical AND of tim_oc3ref and tim_oc5ref
This bit can either have immediate effect or be preloaded and taken into account after an
update event (if preload feature is selected in TIMxCCMR2).
Distortion on channel 2 output:
0: No effect of tim_oc5ref on tim_oc2refc
1: tim_oc2refc is the logical AND of tim_oc2ref and tim_oc5ref
This bit can either have immediate effect or be preloaded and taken into account after an
update event (if preload feature is selected in TIMxCCMR1).
Distortion on channel 1 output:
0: No effect of oc5ref on oc1refc
1: oc1refc is the logical AND of oc1ref and oc5ref
This bit can either have immediate effect or be preloaded and taken into account after an
update event (if preload feature is selected in TIMxCCMR1).
CCR5 is the value to be loaded in the actual capture/compare 5 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR3 register
(bit OC5PE). Else the preload value is copied in the active capture/compare 5 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on tim_oc5 output.
Non-dithering mode (DITHEN = 0)
The register holds the compare value in CCR5[15:0]. The CCR5[19:16] bits are reset.
Dithering mode (DITHEN = 1)
The register holds the integer part in CCR5[19:4]. The CCR5[3:0] bitfield contains the
dithered part.
28 27 26 25
Res. Res. Res.
12 11 10 9
rw rw rw rw
24 23 22
Res. Res. Res.
8 7 6
CCR6[15:0]
rw rw rw
RM0440 Rev 4
21 20 19 18
Res. Res. CCR6[19:16]
rw rw
5 4 3 2
rw rw rw rw
RM0440
17 16
rw rw
1 0
rw rw
