Advanced-control timers (TIM1/TIM8/TIM20)
28.6.24 TIMx timer deadtime register 2 (TIMx_DTR2)(x = 1, 8, 20)
Address offset: 0x054
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:18 Reserved, must be kept at reset value.
Bit 17 DTPE: Deadtime preload enable
Note: This bit can not be modified as long as LOCK level 1, 2 or 3 has been programmed
Bit 16 DTAE: Deadtime asymmetric enable
Note: This bit can not be modified as long as LOCK level 1, 2 or 3 has been programmed
Bits 15:8 Reserved, must be kept at reset value.
Bits 7:0 DTGF[7:0]: Dead-time falling edge generator setup
Note: This bit-field can not be modified as long as LOCK level 1, 2 or 3 has been programmed
