ST STM32G4 Series Reference Manual page 1063

RM0440
Bit 11 TIMxSET1R: HRTIM_SET1xR register update enable
Refer to TIMxCR description.
Bit 10 TIMxDTR: HRTIM_DTxR register update enable
Refer to TIMxCR description.
Bit 9 TIMxCMP4: HRTIM_CMP4xR register update enable
Refer to TIMxCR description.
Bit 8 TIMxCMP3: HRTIM_CMP3xR register update enable
Refer to TIMxCR description.
Bit 7 TIMxCMP2: HRTIM_CMP2xR register update enable
Refer to TIMxCR description.
Bit 6 TIMxCMP1: HRTIM_CMP1xR register update enable
Refer to TIMxCR description.
Bit 5 TIMxREP: HRTIM_REPxR register update enable
Refer to TIMxCR description.
Bit 4 TIMxPER: HRTIM_PERxR register update enable
Refer to TIMxCR description.
Bit 3 TIMxCNT: HRTIM_CNTxR register update enable
Refer to TIMxCR description.
Bit 2 TIMxDIER: HRTIM_TIMxDIER register update enable
Refer to TIMxCR description.
Bit 1 TIMxICR: HRTIM_TIMxICR register update enable
Refer to TIMxCR description.
Bit 0 TIMxCR: HRTIM_TIMxCR register update enable
This bit defines if the master timer MCR register is part of the list of registers to be updated by the
burst DMA.
0: HRTIM_TIMxCR register is not updated by burst DMA accesses
1: HRTIM_TIMxCR register is updated by burst DMA accesses
27.5.75 HRTIM burst DMA data register (HRTIM_BDMADR)
Address offset: 0x3F0
Reset value: 0x0000 0000
31 30 29
wo wo wo
15 14 13
wo wo wo
Bits 31:0 BDMADR[31:0]: Burst DMA data register
Write accesses to this register triggers:
–
–
28 27 26 25
wo wo wo wo
12 11 10 9
wo wo wo wo
the copy of the data value into the registers enabled in BDTxUPR and BDMUPR register
bits
the increment of the register pointer to the next location to be filled
24 23 22
BDMADR[31:16]
wo wo wo
8 7 6
BDMADR[15:0]
wo wo wo
RM0440 Rev 4
High-resolution timer (HRTIM)
21 20 19 18
wo wo wo wo
5 4 3 2
wo wo wo wo
17 16
wo wo
1 0
wo wo
1063/2126
