ST STM32G4 Series Reference Manual page 764

Digital-to-analog converter (DAC)
Bits 26:16 Reserved, must be kept at reset value.
Bit 15 BWST1: DAC channel1 busy writing sample time flag
This bit is systematically set just after Sample and hold mode enable and is set each time the
software writes the register DAC_SHSR1, It is cleared by hardware when the write operation of
DAC_SHSR1 is complete. (It takes about 3 LSI/LSE periods of synchronization).
0:There is no write operation of DAC_SHSR1 ongoing: DAC_SHSR1 can be written
1:There is a write operation of DAC_SHSR1 ongoing: DAC_SHSR1 cannot be written
Bit 14 CAL_FLAG1: DAC channel1 calibration offset status
This bit is set and cleared by hardware
0: calibration trimming value is lower than the offset correction value
1: calibration trimming value is equal or greater than the offset correction value
Bit 13 DMAUDR1: DAC channel1 DMA underrun flag
This bit is set by hardware and cleared by software (by writing it to 1).
0: No DMA underrun error condition occurred for DAC channel1
1: DMA underrun error condition occurred for DAC channel1 (the currently selected trigger is
driving DAC channel1 conversion at a frequency higher than the DMA service capability rate)
Bit 12 DORSTAT1: DAC channel1 output register status bit
This bit is set and cleared by hardware. It is applicable only when the DAC operates in
Double data mode.
0: DOR[11:0] is used actual DAC output
1: DORB[11:0] is used actual DAC output
Bit 11 DAC1RDY: DAC channel1 ready status bit
This bit is set and cleared by hardware.
0: DAC channel1 is not yet ready to accept the trigger nor output data
1: DAC channel1 is ready to accept the trigger or output data
Bits 10:0 Reserved, must be kept at reset value.
22.7.15 DAC calibration control register (DAC_CCR)
Address offset: 0x38
Reset value: 0x00XX 00XX
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:21 Reserved, must be kept at reset value.
Bits 20:16 OTRIM2[4:0]: DAC channel2 offset trimming value
These bits are available only on dual-channel DACs. Refer to
implementation.
Bits 15:5 Reserved, must be kept at reset value.
Bits 4:0 OTRIM1[4:0]: DAC channel1 offset trimming value
764/2126
28 27 26 25
Res. Res. Res.
12 11 10 9
Res. Res. Res.
24 23 22
Res. Res. Res.
8 7 6
Res. Res. Res.
RM0440 Rev 4
21 20 19 18
Res. OTRIM2[4:0]
rw rw rw
5 4 3 2
Res. OTRIM1[4:0]
rw rw rw
Section 22.3: DAC
RM0440
17 16
rw rw
1 0
rw rw
