High-resolution timer (HRTIM)
27.5.63 HRTIM timer external event control register 1 (HRTIM_EECR1)
Address offset: 0x3B0
Reset value: 0x0000 0000
31 30 29
EE5FA
Res. Res.
ST
rw
15 14 13
EE3SN EE3PO
EE3SRC[1:0]
S[0] L
rw rw rw
Bits 31:30 Reserved, must be kept at reset value.
Bit 29 EE5FAST: External event 5 fast mode
Refer to EE1FAST description.
Bits 28:27 EE5SNS[1:0]: External event 5 sensitivity
Refer to EE1SNS[1:0] description.
Bit 26 EE5POL: External event 5 polarity
Refer to EE1POL description.
Bits 25:24 EE5SRC[1:0]: External event 5 source
Refer to EE1SRC[1:0] description.
Bit 23 EE4FAST: External event 4 fast mode
Refer to EE1FAST description.
Bits 22:21 EE4SNS[1:0]: External event 4 sensitivity
Refer to EE1SNS[1:0] description.
Bit 20 EE4POL: External event 4 polarity
Refer to EE1POL description.
Bits 19:18 EE4SRC[1:0]: External event 4 source
Refer to EE1SRC[1:0] description.
Bit 17 EE3FAST: External event 3 fast mode
Refer to EE1FAST description.
Bits 16:15 EE3SNS[1:0]: External event 3 sensitivity
Refer to EE1SNS[1:0] description.
Bit 14 EE3POL: External event 3 polarity
Refer to EE1POL description.
Bits 13:12 EE3SRC[1:0]: External event 3 source
Refer to EE1SRC[1:0] description.
Bit 11 EE2FAST: External event 2 fast mode
Refer to EE1FAST description.
Bits 10:9 EE2SNS[1:0]: External event 2 sensitivity
Refer to EE1SNS[1:0] description.
1046/2126
28 27 26 25
EE5PO
EE5SNS[1:0] EE5SRC[1:0]
L
rw rw rw rw
12 11 10 9
EE2FA
EE2SNS[1:0]
ST
rw rw rw rw
24 23 22
EE4FA
EE4SNS[1:0]
ST
rw rw rw
8 7 6
EE2PO EE1FA
EE2SRC[1:0]
L
rw rw rw
RM0440 Rev 4
21 20 19 18
EE4PO
EE4SRC[1:0]
L
rw rw rw rw
5 4 3 2
EE1PO
EE1SNS[1:0]
ST L
rw rw rw rw
RM0440
17 16
EE3FA EE3SN
ST S[1]
rw rw
1 0
EE1SRC[1:0]
rw rw
