6.3.15 15-** FC Information

Par.
Parameter description
No. #
15-0* Operating Data
15-00 Operating Hours
15-01 Running Hours
15-02 kWh Counter
15-03 Power Up's
15-04 Over Temp's
15-05 Over Volt's
15-06 Reset kWh Counter
15-07 Reset Running Hours Counter
15-08 Number of Starts
15-1* Data Log Settings
15-10 Logging Source
15-11 Logging Interval
15-12 Trigger Event
15-13 Logging Mode
15-14 Samples Before Trigger
15-2* Historic Log
15-20 Historic Log: Event
15-21 Historic Log: Value
15-22 Historic Log: Time
15-23 Historic Log: Date and Time
15-3* Alarm Log
15-30 Alarm Log: Error Code
15-31 Alarm Log: Value
15-32 Alarm Log: Time
15-33 Alarm Log: Date and Time
15-4* Drive Identification
15-40 FC Type
15-41 Power Section
15-42 Voltage
15-43 Software Version
15-44 Ordered Typecode String
15-45 Actual Typecode String
15-46 Frequency Converter Ordering No
15-47 Power Card Ordering No
15-48 LCP Id No
15-49 SW ID Control Card
15-50 SW ID Power Card
15-51 Frequency Converter Serial Number
15-53 Power Card Serial Number
15-55 Vendor URL
15-56 Vendor Name
Default value
4-set-up
0 h
All set-ups
0 h
All set-ups
0 kWh
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
[0] Do not reset
All set-ups
[0] Do not reset
All set-ups
0 N/A
All set-ups
0
2 set-ups
SR
2 set-ups
[0] False
1 set-up
[0] Log always
2 set-ups
50 N/A
2 set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 ms
All set-ups
SR
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 s
All set-ups
SR
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
®
MG.16.A1.02 - VLT
is a registered Danfoss trademark
6 How to Programme the Low Harmonic Drive
Change during
Conver-
operation
sion index
FALSE
74
FALSE
74
FALSE
75
FALSE
0
FALSE
0
FALSE
0
TRUE
-
TRUE
-
FALSE
0
TRUE
-
TRUE
-3
TRUE
-
TRUE
-
TRUE
0
FALSE
0
FALSE
0
FALSE
-3
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
FALSE
0
Type
Uint32
Uint32
Uint32
Uint32
Uint16
Uint16
Uint8
Uint8
Uint32
Uint16
TimD
6
Uint8
Uint8
Uint8
Uint8
Uint32
Uint32
TimeOfDay
Uint8
Int16
Uint32
TimeOfDay
VisStr[6]
VisStr[20]
VisStr[20]
VisStr[5]
VisStr[40]
VisStr[40]
VisStr[8]
VisStr[8]
VisStr[20]
VisStr[20]
VisStr[20]
VisStr[10]
VisStr[19]
VisStr[40]
VisStr[40]
