5.3.5 3-** Reference / Ramps

Par. Parameter description
No. #
3-0* Reference Limits
3-02 Minimum Reference
3-03 Maximum Reference
3-04 Reference Function
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-13 Reference Site
3-14 Preset Relative Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
3-17 Reference 3 Source
3-19 Jog Speed [RPM]
3-4* Ramp 1
5
3-41 Ramp 1 Ramp-up Time
3-42 Ramp 1 Ramp-down Time
3-5* Ramp 2
3-51 Ramp 2 Ramp-up Time
3-52 Ramp 2 Ramp-down Time
3-8* Other Ramps
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
3-84 Initial Ramp Time
3-85 Check Valve Ramp Time
3-86 Check Valve Ramp End Speed [RPM]
3-87 Check Valve Ramp End Speed [HZ]
3-88 Final Ramp Time
3-9* Digital Pot. meter
3-90 Step Size
3-91 Ramp Time
3-92 Power Restore
3-93 Maximum Limit
3-94 Minimum Limit
3-95 Ramp Delay
5-52
Default value
ExpressionLimit
ExpressionLimit
[0] Sum
0.00 %
ExpressionLimit
[0] Linked to Hand / Auto
0.00 %
[1] Analog input 53
[0] No function
[0] No function
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
0.00 s
0.00 s
ExpressionLimit
ExpressionLimit
0.00 s
0.10 %
1.00 s
[0] Off
100 %
0 %
ExpressionLimit
®
MG.20.P3.22 - VLT is a registered Danfoss trademark
VLT AQUA High Power Instruction Manual
4-set-up Change dur- Conver-
ing operation sion index
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -1
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE 67
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
2 set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE 67
All set-ups TRUE -1
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -
All set-ups TRUE 0
All set-ups TRUE 0
All set-ups TRUE -3
Type
Int32
Int32
Uint8
Int16
Uint16
Uint8
Int32
Uint8
Uint8
Uint8
Uint16
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
Uint16
Uint16
Uint16
Uint16
Uint16
Uint16
Uint32
Uint8
Int16
Int16
TimD
