Measuring Cycles for Milling and Machining Centers
5.9 CYCLE997 workpiece: Measuring a sphere and ZO determination
Parameter
_OVR [7]
_OVR [8]
_OVR [9]
_OVR [10]
_OVR [11]
_OVR [12]
_OVR [13]
_OVR [14]
_OVR [15]
_OVR [16]
_OVR [17]
_OVR [18]
_OVR [19]
_OVR [20]
_OVR [21]
_OVR [22]
_OVR [23]
_OVR [24]
_OVR [25]
_OVR [26]
_OVR [27]
_OVR [28]
_OVI [0]
_OVI [2]
_OVI [5]
_OVI [9]
_OVI [11]
_OVI [12]
1) for measuring variants _MVAR=x1x1x9, only, measure 3 spheres
Parameter
Parameter
_SETVAL
_SETV[0]
_SETV[1]
_SETV[2]
_SETV[3]
_SETV[4]
_SETV[5]
5-130
Data type Result
REAL Actual value center point coordinate applicate 1st sphere
REAL Difference sphere diameter 1st sphere
REAL Different center point coordinate abscissa 1st sphere
REAL Difference center point coordinate ordinate 1st sphere
REAL Difference center point coordinate applicate 1st sphere
REAL Actual value sphere diameter 2nd sphere
REAL Actual value of center point coordinates for abscissa 2nd sphere
REAL Actual value of center point coordinates for ordinate 2nd sphere
REAL Actual value of center point coordinates for applicate 2nd sphere
REAL Difference for sphere diameter 2nd sphere
REAL Difference for center point coordinates for abscissa 2nd sphere
REAL Difference for center point coordinates for ordinate 2nd sphere
REAL Difference for center point coordinates for applicate 2nd sphere
REAL Actual value sphere diameter 3rd sphere
REAL Actual value of center point coordinates for abscissa 3rd sphere
REAL Actual value of center point coordinates for ordinate 3rd sphere
REAL Actual value of center point coordinates for applicate 3rd sphere
REAL Difference for sphere diameter 3rd sphere
REAL Difference for center point coordinates for abscissa 3rd sphere
REAL Difference for center point coordinates for ordinate 3rd sphere
REAL Difference for center point coordinates for applicate 3rd sphere
REAL Safe area
INTEGER ZO number
INTEGER Measuring cycle number = 997
INTEGER Probe number
INTEGER Alarm number
INTEGER Status offset request
INTEGER Additional error information on alarm output, internal measurement
evaluation
Data type Meaning
REAL Setpoint sphere diameter
REAL Setpoint center abscissa – 1st sphere
REAL Setpoint center ordinate – 1st sphere
REAL Setpoint center applicate – 1st sphere
REAL Setpoint center abscissa – 2nd sphere
REAL Setpoint center ordinate – 2nd sphere
REAL Setpoint center applicate – 2nd sphere
