Commands Quick Reference
Table 51 :SEARch:SERial:M1553 Commands Summary (continued)
Command
:SEARch:SERial:M1553:
PATTern:DATA <string>
page 1070)
(see
:SEARch:SERial:M1553:
RTA <value> (see
page 1071)
Table 52 :SEARch:SERial:SENT Commands Summary
Command
:SEARch:SERial:SENT:F
AST:DATA <string>
page 1073)
(see
:SEARch:SERial:SENT:M
ODE <mode> (see
page 1074)
:SEARch:SERial:SENT:S
LOW:DATA <data> (see
page 1075)
:SEARch:SERial:SENT:S
LOW:ID <id> (see
page 1076)
Table 53 :SEARch:SERial:SPI Commands Summary
Command
:SEARch:SERial:SPI:MO
DE <value> (see
page 1078)
:SEARch:SERial:SPI:PA
TTern:DATA <string>
page 1079)
(see
:SEARch:SERial:SPI:PA
TTern:WIDTh <width>
page 1080)
(see
170
Query
:SEARch:SERial:M1553:
PATTern:DATA? (see
page 1070)
:SEARch:SERial:M1553:
page 1071)
RTA? (see
Query
:SEARch:SERial:SENT:F
AST:DATA? (see
page 1073)
:SEARch:SERial:SENT:M
page 1074)
ODE? (see
:SEARch:SERial:SENT:S
LOW:DATA? (see
page 1075)
:SEARch:SERial:SENT:S
LOW:ID? (see
page 1076)
Query
:SEARch:SERial:SPI:MO
page 1078)
DE? (see
:SEARch:SERial:SPI:PA
TTern:DATA? (see
page 1079)
:SEARch:SERial:SPI:PA
TTern:WIDTh? (see
page 1080)
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
Options and Query Returns
<string> ::= "nn...n" where n ::=
{0 | 1}
<value> ::= 5-bit integer in
decimal, <hexadecimal>,
<binary>, or <string> from 0-31
< hexadecimal > ::= #Hnn where n
::= {0,..,9|A,..,F}
<binary> ::= #Bnn...n where n ::=
{0 | 1} for binary
<string> ::= "0xnn" where n::=
{0,..,9|A,..,F}
Options and Query Returns
<string> ::= "0xn..." where n ::=
{0,..,9 | A,..,F | X | $}
<mode> ::= {FCData | SCMid |
SCData | CRCerror PPERror}
<data> ::= from -1 (don't care)
to 65535, in NR1 format.
<id> ::= from -1 (don't care) to
255, in NR1 format.
Options and Query Returns
<value> ::= {MOSI | MISO}
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X}
<width> ::= integer from 1 to 10
