What's New in Version 4.07

New features in version 4.07 of the InfiniiVision 4000 X-Series oscilloscope
software are:
• Remote commands for remote command logging.
• Near Field Communication (NFC) trigger mode.
More detailed descriptions of the new and changed commands appear below.
New Commands
Command
:FUNCtion<m>[:FFT]:GATE (see
page
:MARKer:X1:DISPlay (see
page
:MARKer:X2:DISPlay (see
page
:MARKer:Y1:DISPlay (see
page
:MARKer:Y2:DISPlay (see
page
:SYSTem:RLOGger (see
page
:SYSTem:RLOGger:DESTination
(see
:SYSTem:RLOGger:DISPlay (see
page
:SYSTem:RLOGger:FNAMe (see
page
:SYSTem:RLOGger:STATe (see
page
:SYSTem:RLOGger:TRANsparen
t (see
:SYSTem:RLOGger:WMODe
(see
:TRIGger:NFC Commands (see
page
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
405)
456)
459)
465)
467)
1113)
page 1114)
1115)
1116)
1117)
page 1118)
page 1119)
1179)
Description
Specifies whether the FFT is performed on the Main time base
window or the Zoom window when the zoomed time base is
displayed.
Specifies whether the X1 cursor is displayed.
Specifies whether the X2 cursor is displayed.
Specifies whether the Y1 cursor is displayed.
Specifies whether the Y2 cursor is displayed.
Enables or disables remote command logging, optionally
specifying the log file name and write mode.
Specifies whether remote commands are logged to a text file (on a
connected USB storage device), logged to the screen, or both.
Enables or disables the screen display of logged remote
commands and their return values (if applicable).
Specifies the remote command log file name.
Enables or disables remote command logging.
Specifies whether the screen display background for remote
command logging is transparent or solid.
Specifies the remote command logging write mode (either CREate
or APPend).
Commands for setting up the Near Field Communication (NFC)
trigger mode.
1
