Table 15 :FUNCtion<m> Commands Summary (continued)
Command
:FUNCtion<m>:RANGe
page
<range> (see
:FUNCtion<m>:REFerenc
e <level> (see
page 421)
:FUNCtion<m>:SCALe
<scale
value>[<suffix>] (see
page 422)
:FUNCtion<m>:SMOoth:P
OINts <points> (see
page 423)
:FUNCtion<m>:SOURce1
<source> (see
page 424)
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
Query
:FUNCtion<m>:RANGe?
420) page 420)
(see
:FUNCtion<m>:REFerenc
page
e? (see
:FUNCtion<m>:SCALe?
page 422)
(see
:FUNCtion<m>:SMOoth:P
OINts? (see
:FUNCtion<m>:SOURce1?
page 424)
(see
Options and Query Returns
<range> ::= the full-scale
vertical axis value in NR3
format.
The range for ADD, SUBT, MULT is
8E-6 to 800E+3. The range for the
INTegrate function is 8E-9 to
400E+3.
The range for the DIFF function
is 80E-3 to 8.0E12 (depends on
current sweep speed).
The range for the FFT function is
8 to 800 dBV.
<m> ::= 1 to (# math functions)
in NR1 format
<level> ::= the value at center
421)
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
<m> ::= 1 to (# math functions)
in NR1 format
<scale value> ::= integer in NR1
format
<suffix> ::= {V | dB}
<m> ::= 1 to (# math functions)
in NR1 format
<points> ::= odd integer in NR1
page 423)
format
<source> ::= {CHANnel<n> |
FUNCtion<c> | MATH<c> |
WMEMory<r> | BUS<b>}
<n> ::= 1 to (# analog channels)
in NR1 format
<c> ::= {1 | 2 | 3}, must be
lower than <m>
<r> ::= 1 to (# ref waveforms) in
NR1 format
<b> ::= {1 | 2}
<m> ::= 1 to (# math functions)
in NR1 format
