FC 300 Design Guide
PWE high basic behaviour:
Active parameter is only active when communicating through Profibus.
Array means that the parameter is an array.
If bit 13 is true, the parameter can only be reset, not written to.
If bit 12 is true, the parameter value is different from the factory setting.
Bit 11 indicates that text is available.
Bit 10 indicates that additional text is available. Eg. par. 0-01, Language, contains text
for index field 0, English, and for index field 1, German.
If bit 9 is true, the parameter value is read-only and cannot be changed.
If bit 8 is true, upper and lower limits of the parameter value are not relevant.
PWE datatype
LOW
Example
In this example, the master reads the Basic characteristics of par. 0-01, Language. The
following telegram must be sent to the frequency converter:
STX LGE ADR
02 0E 01
default setting ( )
*
256
How to Programme
PKE IND
40 01 00 01
display text [ ] value for use in communication via serial communication port
MG.33.B4.02 - VLT is a registered Danfoss trademark
Bit Description
15 Active parameter
14 Array
13 Parameter value can only be reset
12 Parameter value different from factory
setting
11 Text available
10 Additional text available
9 Read only
8 Upper and lower limit not relevant
0-7 Data type
Dec.
3
4
5
6
7
9
10
13
33
35
PWE PWE
HIGH LOW
00 00 00 00
Data type
Signed 16
Signed 32
Unsigned 8
Unsigned 16
Unsigned 32
Visible string
Byte string
Time difference
Reserved
Bit sequence
PCD1 PCD2
XX XX XX XX
BCC
XX
