FC 300 Design Guide
Start command
Drive stopped
Function:
The list describes the available boolean (TRUE or
FALSE) input for use in the selected logic rule.
*False [0] (default setting) – enters the fixed
•
value of FALSE in the logic rule.
• True [1] – enters the fixed value TRUE
in the logic rule.
Running [2] - see par. 5-13 for further
•
description.
In range [3] - see par. 5-31 for further
•
description.
On reference [4] - see par. 5-31 for
•
further description.
Torque limit [5] - see par. 5-31 for
•
further description.
Current limit [6] - see par. 5-31 for
•
further description.
Out of current range [7] - see par. 5-31
•
for further description.
Below I low [8] - see par. 5-31 for
•
further description.
Above I high [9] - see par. 5-31 for
•
further description.
Below frequency low [11] - see par. 5-31
•
for further description.
Above frequency high [12] - see par. 5-31
•
for further description.
Thermal warning [16] - see par. 5-31
•
for further description.
Mains voltage out of range [17] - see par.
•
5-31 for further description.
• Reversing [18] - see par. 5-31 for
further description.
Warning [19] - see par. 5-31 for further
•
description.
Alarm (trip) [20] - see par. 5-31 for
•
further description.
Alarm (trip lock) [21] - see par. 5-31
•
for further description.
• Comparator 0 [22] – use the result of
comparator 0 in the logic rule.
Comparator 1 [23] – use the result of
•
comparator 1 in the logic rule.
Comparator 2 [24] – use the result of
•
comparator 2 in the logic rule.
Comparator 3 [25] – use the result of
•
comparator 3 in the logic rule.
• Logic rule 0 [26] – use the result of logic
rule 0 in the logic rule.
default setting ( )
*
How to Programme
[39]
[40]
display text [ ] value for use in communication via serial communication port
MG.33.B4.02 - VLT is a registered Danfoss trademark
Logic rule 1 [27] – use the result of logic
•
rule 1 in the logic rule.
Logic rule 2 [28] – use the result of logic
•
rule 2 in the logic rule.
Logic rule 3 [29] – use the result of logic
•
rule 3 in the logic rule.
Digital input DI18 [33] – use the value of DI18
•
in the logic rule (High = TRUE).
• Digital input DI19 [34] – use the value of DI19
in the logic rule (High = TRUE).
Digital input DI27 [35] – use the value of DI27
•
in the logic rule (High = TRUE).
Digital input DI29 [36] – use the value of DI29
•
in the logic rule (High = TRUE).
Digital input DI32 [37] – use the value of DI32
•
in the logic rule (High = TRUE).
• Digital input DI33 [38] – use the value of DI33
in the logic rule (High = TRUE).
13-02 Stop Event
Option:
False
True
Running
In range
On reference
Torque limit
Current limit
Out of current range
Below I low
Above I high
Below speed low
Above speed high
Out of feedb. range
Below feedb. low
Above feedb. high
Thermal warning
Mains out of range
Reversing
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
SL Time-out 0
SL Time-out 1
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
195
