FC 300 Design Guide
Bits 13/14, Set-up selection
Choose between the four parameter set-ups via
bits 13 and 14 according to the shown table:
The function is only possible if you choose Multi
Set-up in par. 0-10. The selection in par. 8-55
Set-up Select determines how bits 13 and 14
links with the corresponding function of the digital
inputs. When the motor is running, you can
only change the set-up if it is linked.
Bit 15, No function/Reverse
Reversion of the motor rotational direction. Bit 15 = "0": No reversion. Bit 15 = "1": Reversion. The
reversion in the default setting in par. 8-54 Reversing Select is "Logic OR". Bit 15 causes a reversion only
when "Bus", "Logic OR", or "Logic AND" is selected ("Logic AND" only in connection with terminal 9, however).
NB!:
Unless otherwise indicated, the control word bit links with the corresponding
digital input function as a logic "OR".
default setting ( )
*
250
How to Programme
display text [ ] value for use in communication via serial communication port
MG.33.B4.02 - VLT is a registered Danfoss trademark
Set-up Bit 13
1 0
2 1
3 0
4 1
Bit 14
0
0
1
1
