FC 300 Design Guide
Function:
Indicates the number of fault events presently
stored in par. 9-45 and 9-47. The buffer capacity
is maximum eight error events.
The buffer and counter is set to 0 by
reset or power-up.
9-45 Fault Code
Option:
Array 64
Function:
This buffer contains the alarm-word for all
alarms and warnings that have occurred since
last reset or power-up.
The buffer capacity is maximum eight error events.
9-47 Fault Number
Option:
Array 64
Function:
This buffer contains the alarm number (e.g.
2 for live zero error, 4 for mains phase loss)
for all alarms and warnings that have occurred
since last reset or power-up.
The buffer capacity is maximum eight error events.
9-52 Fault Situation Counter
Range:
0 - 1000
Function:
Indicates the number of fault events occurred
since last reset or power-up.
9-53 Profibus Warning Word
Option:
Bit:
Meaning:
0
Connection with DP-master is not
1
Not used
2
FDL (Field-bus Data link Layer) is not ok
3
Clear data command received
4
Actual value is not updated
5
Baudrate search
6
PROFIBUS ASIC is not transmitting
7
Initializing of PROFIBUS is not ok
8
Drive is tripped
9
Internal CAN error
10
Wrong configuration data from PLC
11
Wrong ID sent by PLC
12
Internal error occured
13
Not configured
14
Timeout active
15
Warning 34 active
default setting
( )
*
How to Programme
display text
[ ]
value for use in communication via serial communication port
MG.33.B4.02 - VLT is a registered Danfoss trademark
Function:
Displays Profibus communication warnings.
9-63 Actual Baud Rate
Option:
Read only
9.6 kbit/s
19.2 kbit/s
93.75 kbit/s
187.5 kbit/s
500 kbit/s
1500 kbit/s
3000 kbit/s
6000 kbit/s
12000 kbit/s
31.25 kbit/s
45.45 kbit/s
No baud rate found
Function:
Displays the actual PROFIBUS baud rate. The
Profibus Master automatically sets the baud rate.
9-64 Device Identification
Array [10]
Option:
Read only
Array
*
0
Index
Content
[0]
Manufacturer
[1]
Device type
[2]
Version
[3]
Firmware date year
[4]
Firmware date month
[5]
No. of axes
[6]
Vendor specific: PB
Version
[7]
Vendor specific:
Database Version
[8]
Vendor specific: AOC
Version
[9]
Vendor specific: MOC
Version
Function:
The device identification parameter. The
data type is "Array[n] of Unsigned16". The
assignment of the first subindexes is defined
and shown in the table above.
[0]
[1]
[2]
[3]
[4]
[6]
[7]
[8]
[9]
[10]
[11]
[255]
[10]
Value
128 (for Danfoss)
1
xxyy
yyyy
ddmm
variable
xxyy
xxyy
xxyy
xxyy
187
