13.1 Setting Display Functions
13.1.9 Selecting the Initial Operation Display that Appears at Power ON
Description
Setting Details
13-14
The initial Operation Display that appears when the power is turned on can be set.
Parameter
Name
symbol
Home Operation
HOME
Display setting
Display
Setting range
level
SP1: SP Display
OUT1: OUT Display
HCO: Heating/cooling OUT Display
VP: Valve Position Display
MV: Position Proportional
Computation Output Display
PRO PID1: PID Number Display
HC1: Heater Break Alarm-1
Current Display
HC2: Heater Break Alarm-2
Current Display
PV: PV Analog Input Display
CS1 to CS5: SELECT Display 1 to 5
Menu symbol
DISP
IM 05P01D31-01EN
