Setting Details
IM 05P01D31-01EN
Parameter
Name
symbol
Bar-graph display
BAR1
registration
Bar-graph
BDV deviation display
band
Note1: The bar-graph deviation display band (BDV) is enabled when the deviation is set to the
BAR1.
13.1 Setting Display Functions
Display
Setting range
level
0: Disable
1:OUT, Heating-side OUT, Internal
value in Position proportional
control
2: Cooling-side OUT
STD 3: PV
4: SP
5: Deviation
6 to 16: Disable
17: Feedback input (valve opening)
18: PV terminals analog input
0.0 to 100.0% of PV input range
STD
span (EUS)
Menu symbol
DISP
13
13-11
