Setting Details
IM 05P01D31-01EN
Parameter
Name
symbol
Zone PID
ZON
selection
Reference point
RP1 to RP3
1 to 3
Number of PID
PIDG.
groups
PID number
PID
(display only)
Note1: A currently-used PID number is displayed for the parameter PID.
Note
When changing the setpoint of the parameter PIDG., if the setpoint of the parameter PIDN
which belongs to the SP menu is larger than that of the parameter PIDG., the PIDN setpoint is
changed to the PIDG. setpoint.
Display
Setting range
level
0: SP group number selection 1
1: Zone PID selection (selection
by PV)
2: Zone PID selection (selection
STD
by target SP)
3: SP group number selection 2
4: Zone PID selection (selection
by SP)
0.0 to 100.0% of PV input range
STD (EU)
(RP1 ≤ RP2 ≤ RP3)
STD 1 to 4
1 to 4, R: PID group for reference
EASY
deviation
8.4 Switching PID
Menu symbol
CTL
ZONE
CTL
8
MODE
8-27
