PV Red/white Switch (PVRW)
Bit-0 to Bit-2 of SP Number (SP.B0 to SP.B2)
Setting Details
IM 05P01D31-01EN
PV color can be switched using contact input. (Status switch)
Contact status
ON Red color
OFF White color
Set "10" to the parameter PCMD.
The SP number can be switched using contact input. There are two methods to specify
SP number.
• Status switch 1 (Operation by keystroke or via communication is enabled depending
on the conditions.)
SP number
SP.B2
1 OFF
2 OFF
3 OFF
4 ON
*1: "1" when the contact input is turned on and "0" when turned off.
*2: SP number can be switched by keystroke or via communication when all contact inputs of SP.B0
to SP.B2 are turned off.
*3: SP number cannot be switched by keystroke or via communication when any contact input of
SP.B0 to SP.B2 is turned on.
*4: The contact input is turned off when the bit of SP number is not assigned to the contact input.
*5: The immediately preceding SP number is held when all contact inputs are turned off.
• Status switch 2 (Operation by keystroke or via communication is disabled.)
SP number
SP.B2
1
OFF
2
OFF
3
OFF
4
OFF
*1: "1" when the contact input is turned on and "0" when turned off.
*2: Contact input is turned off when the bit of SP number is not assigned to the contact input.
Parameter
Name
symbol
Bit changing method of
SP.BC
SP number
12.1 Setting Contact Input Function
Operation
–
–
Contact status
SP.B1 SP.B0
OFF ON
ON OFF
ON ON
OFF OFF
Contact status
SP.B1 SP.B0
OFF OFF
OFF ON
ON OFF
ON ON
Display
Setting range
level
0: Status switch 1
STD
1: Status switch 2
Remark
12
Menu symbol
DI.NU
