No. in figure Name
PV display
(1)
(white or red)
Group display
(2)
(green)
Symbol display
(3)
(orange)
(4) Data display (orange)
Bar-graph display
(5)
(orange)
Event indicator
(6)
(orange)
Key navigation
(7) indicator
(green)
Parameter display
(8) level indicator
(green)
Status indicator
(9)
(green and red)
(10) Security indicator (red)
Ladder operation
(11)
indicator (green)
3.1 Names and Functions of Display Parts
Description
Displays PV.
Displays an error code if an error occurs.
Displays the scrolling guide in the Menu Display and
Parameter Setting Display when the guide display ON/
OFF is set to ON.
Displays a group number (1 to 4, or R) and terminal area
(E1 to E4).
1 to 4 represent SP numbers in the Operation Display.
R and E1 to E4 are displayed in the Parameter Setting
Display.
Displays a parameter symbol.
Displays a parameter setpoint and menu symbol.
Displays control output value (OUT) and measured input
value (PV).
The data to be displayed can be set by the parameter.
Initial value: deviation, in Heating/cooling control: heating-
side control output
Lit when the alarms 1 to 4 occur.
Event displays other than alarms can be set by the
parameter.
Lit or blinks when the Up/Down or Left/Right arrow key
operation is possible.
Displays the setting conditions of the parameter display
level function.
Parameter display level
Easy setting mode
Standard setting mode
Professional setting mode
Displays the operating conditions and control status.
Display Description
REM Lit when in remote mode (REM).
STOP Lit when in stop mode (STOP).
Lit when in manual mode (MAN).
MAN
Blinks during auto-tuning.
Lit if a password is set. The setup parameter settings are
locked.
Lit while the ladder program operation is executed.
3
EASY PRO
Lit Unlit
Unlit Unlit
Unlit Lit
