18.2 List of Parameters
18.2.1 Operation Parameters
18-8
Operation Mode Menu (Menu: MODE)
Parameter
Name
symbol
S.R STOP/RUN switch
REMOTE/LOCAL
R.L
switch
AT Auto-tuning switch
SP number
SPNO.
selection
PID PID number
Display
Setting range
level
STOP: Stop mode
RUN: Run mode
Preset output (PO) is generated in
EASY
STOP mode.
Default: Not displayed. STOP/RUN
switch is assigned to contact input.
LCL: Local mode
REM: Remote mode
EASY
(Displayed only in cases where the
communication is specified.)
OFF: Disable
1 to 4: Perform auto-tuning. Tuning
result is stored in the specified
EASY
numbered PID.
R: Tuning result is stored in the
PID for reference deviation.
1 to 4 (Depends on the setup
EASY
parameter SPGR. setting.)
The PID group number being
selected is displayed.
EASY
1 to 4, R: PID group for reference
deviation
Initial value
RUN
LCL
OFF
1
1
IM 05P01D31-01EN
