Contact Input
Contact Output
24 V DC Loop Power Supply
IM 05P01D31-01EN
Up to 12 contact inputs can be incorporated. The operation modes can be switched.
PID control and sequence control can be performed simultaneously using the ladder
sequence function.
For details, see the table of Model and Suffix Codes.
► Chapter 12 Contact Input/Output Functions
Up to 13 contact outputs can be incorporated. Contact output can output events such as
alarms.
PID control and sequence control can be performed simultaneously using the ladder
sequence function.
For details, see the table of Model and Suffix Codes.
► Chapter 11 Alarm Functions
24 V DC loop power supply can be supplied to 2-wire transmitter.
► 17.4.10 24 V DC Loop Power Supply Wiring
2-wire transmitter
1.2 Input/Output Function
UT35A/UT32A
