Model and Suffix Codes of UT32A (for Detailed model)
Model
Suffix code
UT32A
Fixed code
-NNN
-1
-2
Display language (*1)
-3
-4
Case color
Output 1 (*2) (*3) (*5)
Output 2 (*2) (*3) (*4) (*5)
Retransmission output (*4)
Heater break alarm (*5)
E1 terminal area (*6) (*7)
Power supply
Additional treatment (*8)
IM 05P01D31-01EN
Optional
suffix
code
Digital Indicating Controller (provided with 2 DIs, and 3 DOs) (Power supply:
100-240 V AC)
Always "-NNN"
English
German
French
Spanish
0
White (Light gray)
1
Black (Light charcoal gray)
-A
Analog output (current/voltage pulse)
-R
Relay output (c-contact)
-U
Universal output (current/voltage pulse/relay)
-T
Triac output
-P
Position proportional output
A
Analog output (current/voltage pulse)
R
Relay output (a-contact)
U
Universal output (current/voltage pulse/relay)
N
None
/RT
Retransmission output or 15 V DC power supply
/HA
Heater break alarm
/L1
24 V DC loop power supply
/CH1
RS485 communication (Max. 38.4 kbps, 2-wire/4-wire)
/LCH1
24 V DC loop power supply and RS485 communication (Max. 38.4 kbps, 2-wire)
/X1
5 additional DIs
/Y1
5 additional DOs
/W1
2 additional DIs and 2 additional DOs
/DC
Power supply 24 V AC/DC
/CT
Coating
*1:
English, German, French, and Spanish can be displayed as the guide display.
*2:
For heating/cooling output, both Output 1 and Output 2 should be specified. Not available
when Output 2 is "N". For position proportional output, specify "-P" for Output 1 and "N" for
Output 2.
*3:
When the code for Output 1 is "-R" or "-U" and Output 2 is "R" or "U", Output 1 is changed
from the contact point c to the contact point a. When the code for Output 1 is specified to
"-T", only "A" or "N" is available for Output 2.
*4:
The /RT option can be specified only when the code for Output 2 is "R" or "N."
*5:
The /HA option can be specified in the combination of Output 1 and Output 2 codes except for
"-PN."
*6:
Only one option is available for E1 terminal area.
*7:
The /L1 or /LCH1 option can be specified only when the code for Output 2 is "N."
*8:
When the /CT option is specified, the UT32A does not conform to the safety standards (UL
and CSA) and CE marking.
Coating Treatment
(1) HumiSeal coating treatment
Apply HumiSeal coating to the printed circuit board assembly.
Do not apply HumiSeal coating to the following parts: connector, gold-plated contact
area, relay part, RJC device, and in the vicinity of the push switch/LED lamp.
(2) Apply terminal coating to the gold-plated contact area on the printed circuit board.
Notes
▪ There are two treatments as described above, but we do not guarantee their
effectiveness.
We do not supply any test data on these treatments.
▪ Do not apply any treatment to the screw terminal area on the back side of the
instrument.
Description
