YOKOGAWA UT Advanced UT32A User Manual page 202

IM 05P01D31-01EN
Alarm Status
The alarm status can be output to the contact output. (The setpoints below are I relay
numbers.)
► I relay: UTAdvanced Series Communication Interface (RS-485, Ethernet) User's Manual
Setpoint
Alarm output
Alarm status
status
4321 4353
4322 4354
4323 4355
4325 4357
• Alarm status: The internal alarm status is turned on when an alarm occurs and
turned off in normal condition
• Alarm output status: Contact output status when an alarm occurs (ON in alarm
condition and OFF in normal condition)
However, the output status depends on the settings of energized/de-energized of alarm,
latch action, and contact type.
The above assumes that the contact type is energized. (Then contact is turned on when
an event occurs.)
To output the normal alarm to the contact output, assign the alarm output status.
► Alarm action: 11.1 Setting Alarm Type
Alarm Latch Status
The alarm latch status can be output to another contact output irrespective of the setting
of alarm-1 to -4 type (AL1 to AL4). (The setpoints below are I relay numbers.)
► I relay: UTAdvanced Series Communication Interface (RS-485, Ethernet) User's Manual
Setpoint
Alarm output Alarm output Alarm output
latch 1 status latch 2 status latch 3 status
4385 4417
4386 4418
4387 4419
4389 4421
• Alarm output latch 1, 2, 3, and 4 status: ON in the latch status of the contact output
when an alarm occurs and OFF in the latch release status of the contact output in
normal condition
However, the output status depends on the settings of contact type.
► Alarm latch action: 11.1 Setting Alarm Type
12.2 Setting Contact Output Function
Function
Alarm 1
Alarm 2
Alarm 3
Alarm 4
Alarm output
latch 4 status
4449 4481 Alarm 1
4450 4482 Alarm 2
4451 4483 Alarm 3
4453 4485 Alarm 4
Function
