YOKOGAWA UT Advanced UT32A User Manual page 308

IM 05P01D31-01EN
RS-485 Communication Setting Menu (Menu: R485) (E1 and E3 terminal area)
Parameter
Name
symbol
PSL Protocol selection
BPS
Baud rate
PRI Parity
STP Stop bit
DLN Data length
ADR Address
Minimum response
RP.T
time
When each parameter is displayed, the terminal area (E1 or E3) is displayed on Group display.
• Parameter: PSL, BPS, STP, DLN, ADR, RP.T
Display
Setting range
level
PCL: PC link communication
PCLSM: PC link communication
(with checksum)
LADR: Ladder communication
CO-M: Coordinated master station
CO-S: Coordinated slave station
EASY MBASC: Modbus (ASCII)
MBRTU: Modbus (RTU)
CO-S1: Coordinated slave station
(Loop-1 mode)
CO-S2: Coordinated slave station
(Loop-2 mode)
P-P: Peer-to-peer communication
600: 600 bps
1200: 1200 bps
2400: 2400 bps
EASY 4800: 4800 bps
9600: 9600 bps
19200: 19.2k bps
38400: 38.4k bps
NONE: None
EASY EVEN: Even
ODD: Odd
EASY 1: 1 bit, 2: 2 bits
EASY 7: 7 bits, 8: 8 bits
EASY 1 to 99
PRO 0 to 10 (x10ms)
18.2 List of Parameters
Initial value
MBRTU
19200
EVEN
1
8
1
0
18-21
18
