YOKOGAWA UT Advanced UT32A User Manual page 58

IM 05P01D31-01EN
Input Function (Continued)
Parameter
Name
symbol
PV input scale
SDP decimal point
position
Maximum value of
SH
PV input scale
Minimum value of
SL
PV input scale
► Input setting: 7.1 Setting Functions of PV Input
Output Function
Parameter
Name
symbol
OT Output type selection
Control output cycle
time
Heating-side control
CT
output cycle time
(in Heating/cooling
control)
Cooling-side control
CTc
output cycle time
► Output type: 10.1 Setting Control Output Type
► Cycle time: 10.2 Setting Control Output Cycle Time
5.1 Setting Using Quick Setting Function
Display
Setting range
level
0: No decimal place
1: One decimal place
EASY 2: Two decimal places
3: Three decimal places
4: Four decimal places
EASY
-19999 to 30000, (SL<SH),
| SH - SL | ≤ 30000
EASY
Display
Setting range
level
Control output or Heating-side
control output (Lower two digits)
00: OFF
01: OUT terminals (voltage pulse)
02: OUT terminals (current)
03: OUT terminals (relay/triac)
06: OUT2 terminals (relay)
07: RET/OUT2 terminals (voltage
pulse)
08: RET/OUT2 terminals (current)
EASY
Cooling-side control output (Upper
two digits)
00: OFF
01: OUT terminals (voltage pulse)
02: OUT terminals (current)
03: OUT terminals (relay/triac)
06: OUT2 terminals (relay)
07: RET/OUT2 terminals (voltage
pulse)
08: RET/OUT2 terminals (current)
EASY
0.5 to 1000.0 s
EASY
Menu symbol
PV
5
Menu symbol
OUT
5-5
