Setting Details
IM 05P01D31-01EN
Parameter
Name
symbol
Preset output
Heating-side preset
PO
output (in Heating/
cooling control)
Cooling-side preset
POc
output
Sub-preset output (in
SU.PO Two-position two-level
control)
PIDN PID number selection
PIDG. Number of PID groups
Note1: The PID number (1 to 4, R) is displayed on Group display while each parameter is displayed.
Note
When changing the setpoint of the parameter PIDG., if the setpoint of the parameter PIDN
which belongs to the SP menu is larger than that of the parameter PIDG., the PIDN setpoint is
changed to the PIDG. setpoint.
For ON/OFF output (ON/OFF output or ON/OFF output in Two-position two-level control
or Heating/cooling control), 0.0% is output when the setting value is 0.0% or less and
100.0% is output when 0.1% or more.
10.12 Setting Preset Output Value
Display
Setting range
level
In STOP mode, fixed control
output can be generated.
EASY
In Position proportional
control, Valve opening can
be set;
EASY
-5.0 to 105.0%
In STOP mode, fixed sub-
control output can be
EASY
generated.
0%, 100%
EASY 1 to 4
STD 1 to 4
Menu symbol
PID
SP
CTL
10
