17.4 Wiring
(External)
Terminating resistor
220 Ω 1/4 W
17-22
2-wire Wiring
UT
RSB (+)
RSA (–)
SG
Communication
cable
Class D grounding
(grounding resistance
of 100 Ω or less)
UT32A
Terminal (For Standard model) Suffix code: Type 2=1,
symbol and with optional suffix code /LP
above (For Detailed model) Optional suffix code:
RSB (+)
RSA (–)
SG
► Details of communication parameter settings and communication functions: UTAdvanced Series
Communication Interface (RS-485, Ethernet) User's Manual
► Details of Peer-to-peer communication: LL50A Parameter Setting Software User's Manual
UT
RSB (+)
RSA (–)
SG
Communication
cable
Class D grounding
(grounding resistance
of 100 Ω or less)
UT32A
/LCH1
301
302
303
UT
RSB (+)
(External)
Terminating resistor
RSA (–)
220 Ω 1/4 W
SG
IM 05P01D31-01EN
