18.2 List of Parameters
18-32
AL1-AL3 Function Registration Menu (Menu: ALM)
Parameter
Name
symbol
AL1 function
AL1.S
selection
AL2 function
AL2.S
selection
AL3 function
AL3.S
selection
OUT relay function
OR.S
selection
OUT2 relay function
OR2.S
selection
AL1.D AL1 contact type
AL2.D AL2 contact type
AL3.D AL3 contact type
OUT relay contact
OR.D
type
OUT2 relay contact
OR2.D
type
DO Setting Menu (Menu: DO) (E1 and E4 terminal area)
Parameter
Name
symbol
DOn1 function
DO1.S
selection
DOn2 function
DO2.S
selection
DOn3 function
DO3.S
selection
DOn4 function
DO4.S
selection
DOn5 function
DO5.S
selection
DO1.D
DOn1 contact type
DO2.D DOn2 contact type
DO3.D
DOn3 contact type
DO4.D DOn4 contact type
DO5.D
DOn5 contact type
n: Terminal area number (1 or 4)
Display
Setting range
level
Set an I relay number.
STD
Setting range: 4001 to 6000
STD
No function: OFF
Alarm 1: 4353
STD
Alarm 2: 4354
Alarm 3: 4355
STD
Alarm 4: 4357
AUTO (ON ) / MAN (OFF) status: 4193
REM (ON) / LCL (OFF) status: 4194
STD
STOP (ON) / RUN (OFF) status: 4195
FAIL (Normally ON) output: 4256
PRO
0: When the event of assigned
PRO
function occurs, the contact
PRO
output is closed.
1: When the event of assigned
PRO
function occurs, the contact
output is opened.
PRO
Display
Setting range
level
STD
Same as AL1.S.
STD
Initial value of E1 and E3 teminal
STD
area
All DO settings are OFF.
STD
STD
PRO
0: When the event of assigned
PRO function occurs, the contact
output is closed.
PRO
1: When the event of assigned
PRO function occurs, the contact
output is opened.
PRO
Initial value
4353
4354
4355
OFF
OFF
0
0
0
0
0
Initial value
OFF
OFF
OFF
OFF
OFF
0
0
0
0
0
