12.1 Setting Contact Input Function
Bit-0 to Bit-2 of PID Number (PN.B0 to PN.B2)
Setting Details
12-4
The PID number can be switched using contact input. There are two methods to specify
a PID number.
• Status switch 1 (Operation by keystroke or via communication is enabled depending
on the conditions.)
PID number
1
2
3
4
*1: "1" when the contact input is turned on and "0" when turned off.
*2: PID number can be switched by keystroke or via communication when all contact inputs of
PN.B0 to PN.B3 are turned off.
*3: PID number cannot be switched by keystroke or via communication when any contact input of
PN.B0 to PN.B3 is turned on.
*4: The contact input is turned off when the bit of PID number is not assigned to the contact input.
• Status switch 2 (Operation by keystroke or via communication is disabled.)
PID number
1
2
3
4
*1: "1" when the contact input is turned on and "0" when turned off.
*2: Contact input is turned off when the bit of PID number is not assigned to the contact input.
Parameter
Name
symbol
Bit changing method of
PN.BC
PID number
Contact status
PN.B2 PN.B1
OFF OFF
OFF ON
OFF ON
ON OFF
Contact status
PN.B2 PN.B1
OFF OFF
OFF OFF
OFF ON
OFF ON
Display
level
0: Status switch 1
PRO
1: Status switch 2
PN.B0
ON
OFF
ON
OFF
PN.B0
OFF
ON
OFF
ON
Setting range Menu symbol
DI.NU
