PV Input Setting Menu (Menu: PV) (Continued from previous page)
Parameter
Name
symbol
PV input scale
SDP
decimal point
position
Maximum
SH
value of PV
input scale
Minimum value
SL
of PV input
scale
PV input
BSL
burnout action
PV input
reference
RJC
junction
compensation
PV input
ERJC
external RJC
setpoint
PV analog
A.BS
input bias
PV analog
A.FL
input filter
Input Range / SP Limiter Setting Menu (Menu: MPV)
Parameter
Name
symbol
Control PV input
P.UNI
unit
Control PV input
P.DP
decimal point
position
Maximum value of
P.RH
control PV input
range
Minimum value of
P.RL
control PV input
range
SPH
SP high limit
SPL
SP low limit
Display
Setting range
level
0: No decimal place
1: One decimal place
EASY
2: Two decimal places
3: Three decimal places
4: Four decimal places
EASY
-19999 to 30000, (SL<SH), | SH - SL | ≤
30000
EASY
OFF: Disable
STD
UP: Upscale
DOWN: Downscale
OFF: RJC OFF
PRO
ON: RJC ON
PRO
-10.0 to 60.0 (°C)
-100.0 to 100.0% of PV input range span
STD
(EUS)
STD
OFF, 1 to 120 s
Display
Setting range
level
-: No unit
C: Degree Celsius
-: No unit
STD
--: No unit
---: No unit
F: Degree Fahrenheit
0: No decimal place
1: One decimal place
STD
2: Two decimal places
3: Three decimal places
4: Four decimal places
STD
-19999 to 30000, (P.RL<P.RH), |
P.RH - P.RL | ≤ 30000
STD
STD
0.0 to 100.0% of PV input range
(EU), (SPL<SPH)
STD
18.2 List of Parameters
Initial
value
Depends
on the
input type
Depends
on the
input type
Depends
on the
input type
Depends
on the
input type
ON
0.0
0.0 % of
PV input
range
span
OFF
Initial value
Same as PV
input unit
1
Depends on
the input type
Depends on
the input type
100.0 % of PV
input range
0.0 % of PV
input range
18-17
