Setting Details
IM 05P01D31-01EN
Parameter
Name
symbol
A/M AUTO/MAN switch
R/L REMOTE/LOCAL switch
S/R STOP/RUN switch
AUTO Switch to AUTO
MAN Switch to MAN
REM
Switch to REMOTE
LCL Switch to LOCAL
AT Auto-tuning START/STOP switch
LAT Latch release
LCD LCD backlight ON/OFF switch
PVRW PV red/white switch
MG1 Message display interruption 1
MG2 Message display interruption 2
MG3 Message display interruption 3
MG4 Message display interruption 4
SP.B0 Bit-0 of SP number
SP.B1 Bit-1 of SP number
SP.B2 Bit-2 of SP number
PN.B0 Bit-0 of PID number
PN.B1 Bit-1 of PID number
PN.B2 Bit-2 of PID number
Bit-0 of manual preset output
MP.B0
number
Bit-1 of manual preset output
MP.B1
number
Bit-2 of manual preset output
MP.B2
number
12.1 Setting Contact Input Function
Display
Setting range
level
STD
STD
STD
STD
STD
STD
STD
STD
STD
STD
STD
See the following
PRO
section, "UT35A
PRO
DI and Setpoint"
or "UT32A DI and
PRO
Setpoint".
PRO
EASY
EASY
EASY
STD
STD
STD
STD
STD
STD
Menu symbol
DI.SL
12
DI.NU
12-7
