18.2 List of Parameters
18-26
Display Function Setting Menu (Menu: DISP) (Continued from previous page)
Parameter
Name
symbol
EV1 to EV4
EV1 to
display condition
EV4
registration
PV display area
PV.D
ON/OFF
Setpoint display
SP.D
area ON/OFF
Status display
STS.D
area ON/OFF
SPD Scroll speed
Guide display
GUID
ON/OFF
Home Operation
HOME
Display setting
ECO Economy mode
BRI Brightness
Display
Setting range
level
Setting range: 4001 to 6304
OFF: Disable
4321: Link to alarm 1 (Lit when the alarm occurs)
4322: Link to alarm 2 (Lit when the alarm occurs)
4323: Link to alarm 3 (Lit when the alarm occurs)
4325: Link to alarm 4 (Lit when the alarm occurs)
4529: Heater break alarm 1 (Lit when the alarm
occurs)
4530: Heater break alarm 2 (Lit when the alarm
occurs)
5025 to 5026: Link to DI1-DI2 (Lit when the
PRO
contact is closed)
5041 to 5045: Link to DI11-DI15 (E1-terminal
area) (Lit when the contact is closed)
5153 to 5155: Link to AL1-AL3 (Lit when the
contact is closed)
5169 to 5170: Link to DO11-DO12 (E1-terminal
area) (Lit when the contact is closed)
5217 to 5221: Link to DO41-DO45 (E4-terminal
area) (Lit when the contact is closed)
For other functions, see the UTAdvanced Series
Communication Interface User's Manual.
PRO
PRO OFF: Nondisplay, ON: Display
PRO
PRO (Slow) 1 to 8 (Quick)
OFF: Nondisplay
STD
ON: Display
SP1: SP Display
OUT1: OUT Display
HCO: Heating/cooling OUT Display
VP: Valve Position Display
MV: Position Proportional Computation
PRO Output Display
PID1: PID Number Display
HC1: Heater Break Alarm-1 Current Display
HC2: Heater Break Alarm-2 Current Display
PV: PV Analog Input Display
CS1 to CS5: SELECT Display 1 to 5
OFF: Disable
1: Economy mode ON (All indications
except PV display OFF)
STD
2: Economy mode ON (All indications
OFF)
3: Brightness 10 % (All indications)
EASY (Dark) 1 to 5 (Bright)
Initial value
EV1: 4321
EV2: 4322
EV3: 4323
EV4: 4325
ON
ON
ON
4
ON
SP1
OFF
3
