18.2 List of Parameters
18-18
Output Setting Menu (Menu: OUT)
Parameter
Name
symbol
Output type
OT
selection
Control output cycle
time
Heating-side control
CT
output cycle time
(in Heating/cooling
control)
Cooling-side control
CTc
output cycle time
Automatic valve
V.AT
position adjustment
Valve position
V.RS
setting reset
Fully-closed valve
V.L
position setting
Fully-open valve
V.H
position setting
TR.T Valve traveling time
Valve adjusting
V.MOD
mode
Display
Setting range
level
Control output or Heating-side
control output (Lower two digits)
00: OFF
01: OUT terminals (voltage pulse)
02: OUT terminals (current)
03: OUT terminals (relay/triac)
06: OUT2 terminals (relay)
07: RET/OUT2 terminals (voltage
pulse)
08: RET/OUT2 terminals (current)
EASY
Cooling-side control output (Upper
two digits)
00: OFF
01: OUT terminals (voltage pulse)
02: OUT terminals (current)
03: OUT terminals (relay/triac)
06: OUT2 terminals (relay)
07: RET/OUT2 terminals (voltage
pulse)
08: RET/OUT2 terminals (current)
EASY
0.5 to 1000.0 s
EASY
OFF: Stop automatic adjustment
EASY
ON: Start automatic adjustment
Setting V.RS to ON resets the
valve adjustment settings and
EASY
causes the indication "V.RS" to
blink.
Pressing the SET/ENTER key
with valve position set to the fully-
closed position by Down arrow
EASY
key causes the adjusted value to
be stored. When V.L adjustment is
complete, V.L stops blinking.
Pressing the SET/ENTER key
with valve position set to the fully-
opened position by Up arrow key
EASY
causes the adjusted value to be
stored. When V.H adjustment is
complete, V.H stops blinking.
STD 5 to 300 s
0: Valve position feedback type
1: Valve position feedback type
(moves to the estimating type if
STD
a feedback input error or break
occurs.)
2: Valve position estimating type
Initial value
Standard type:
00.03
Heating/
cooling type:
06.03
30.0 s
30.0 s
OFF
OFF
-
-
60 s
0
