3.4
Brief Description of Setting Details (Parameters)
Setting Details
IM 05P01D31-01EN
This manual describes the Setting Details as follows in addition to the functional
Description.
(Display Example)
Parameter
Name
symbol
Alarm-1 to -4
A1 to A4
setpoint
(1) Parameter symbol: Symbol displayed on Symbol display on the front panel.
(2) Name: Parameter name
(3) Display level: Indicates the parameter display level.
(4) Setting range: Parameter setting range
(5) Menu symbol: Indicates the menu to which the parameter belongs.
: Operation parameter
: Setup parameter
Parameter Display Level
Display level
Easy setting mode: The minimum
EASY
necessary parameters are displayed.
Standard setting mode: The wider
range of parameters than those
STD
shown in Easy setting mode are
displayed.
Professional setting mode: All
PRO
parameters are displayed.
Note
For more intelligible display operation of parameters and the references, see Chapter 18,
"Parameter Map."
Display
Setting range
level
Set a display value of setpoint of
PV alarm, SP alarm, deviation
alarm, output alarm, or velocity
alarm.
EASY
-19999 to 30000 (Set a value
within the input range.)
Decimal point position depends on
the input type
Corresponding parameters are displayed in
all modes.
Corresponding parameters are displayed only
in Standard setting mode and Professional
setting mode.
Parameter display level indicators "EASY"
and "PRO" are unlit in Standard setting
mode.
*: "STD" is the symbol used in this manual
only.
Corresponding parameters are displayed only
in Professional setting mode.
Menu symbol
SP
Description
3-9
3
