3.1 Names and Functions of Display Parts
(2) Group display
(9) Status indicator
(10) Security indicator
(11) Ladder operation indicator
(8) Parameter display level indicator
(11) Ladder operation indicator
(10) Security indicator
3-2
UT35A
UT32A
(2) Group display
(9) Status indicator
(1) PV display
(4) Data display
(3) Symbol display
(5) Bar-graph display
(6) Event indicator
(7) Key navigation indicator
(8) Parameter display level
(2) + (3) + (4) : Setpoint display
(1) PV display
(3) Symbol display
(4) Data display
(5) Bar-graph display
(6) Event indicator
(7) Key navigation indicator
(2) + (3) + (4) : Setpoint display
indicator
IM 05P01D31-01EN
