4.0 Configuration
4.6.3 VPN > L2TP Client
The BulletPlus can operate as a L2TP Client, allowing a VPN connection to be made with a L2TP Server.
Enter a name for the VPN Tunnel. Up to 16 different tunnels can be
created, each requiring a unique name.
Used to enable (checked) is disable (unchecked) the VPN tunnel.
© Microhard Systems Inc.
Image 4-6-3: VPN > Client to Gateway
Tunnel Name
Values (chars)
tunnel1
Enable
Values (checkbox)
Enable (Checked)
96
