4.0 Configuration
4.4.2 Wireless > Radio1

Radio1 Phy Configuration

The top section of the Wireless Configuration allows for the configuration of the physical radio module. You
can turn the radio on or off, and select the channel bandwidth and frequency as seen below.
This option is used to turn the radio module on or off. If turned off
Wireless connections can not be made. The default is On.
The Mode defines which wireless standard to use for the wireless
network. The BulletPlus supports 802.11/b/g/n modes as seen here.
Select the appropriate operating mode from the list.
The options below are dependant and vary on the operating mode
chosen here.
Only appears when using 802.11b or b/g modes. Lower channel
bandwidths may provide longer range and be less susceptible to noise
but at the trade off of data rates. Higher channel bandwidth may
provide greater data rates but will be more susceptible to noise and
shorter distance potentials.
© Microhard Systems Inc.
Image 4-4-2: Wireless > Radio Configuration
Radio
Values (selection)
On / Off
Mode
Values (selection)
802.11B ONLY
802.11BG
802.11NG
Channel Bandwidth
Values (selection)
20MHz Normal Rate
