1.0 Overview

1.2 Specifications

BulletPlus
General
© Microhard Systems Inc.
BulletPlus Supported Bands:
(North America)
BulletPlus Supported Bands:
(China)
BulletPlus Data Features:
(North America)
BulletPlus Data Features:
(China)
Serial Interface: RS232, RS485, RS422
Serial Baud Rate: 300bps to 921kbps
USB*: USB 2.0
(*Future) USB Console Port
USB to Serial Data Routing
USB to Ethernet Data Routing (NDIS)
Current Consumption:
(@12VDC)
LTE FDD (Bands 1-5,7,8,13,17,18,19,20)
UMTS | DC-HSPA+ (Bands 1,2,4,5,8)
GSM | GPRS | EDGE (Bands 2,3,5,8)
3GPP Protocol Stack Release 9
LTE FDD: Band 1, 3, 8, all bands with diversity
LTE TDD: Band 39, 40, 41(38), all bands with diversity
DC-HSPA+/HSPA+/HSPA/UMTS: Band 1, 5, 8, 9, all bands
with diversity
TD-SCDMA: Band 34, 39, all bands with diversity
GSM/GPRS/EDGE: 1800 MHz/900 MHz
LTE: DL 100 Mbps, UL 50 Mbps
HSPA+: DL 42 Mbps, UL 5.7 Mbps
HSPA+: DL 21 Mbps, UL 5.7 Mbps
WCDMA: DL/UL 384 kbps
EDGE Class 33: DL/UL 236.8 kbps
GPRS Class 33: DL/UL 85.6kbps
LTE FDD: UL 50Mbit/s, DL 150Mbit/s @20M BW cat4
LTE TDD: UL 10Mbit/s; DL 112Mbit/s @20M BW cat4
TD-SCDMA PS: UL 384 kbit/s; DL 384 kbit/s
TD-HSPA+: UL 2.2 Mbit/s; DL 4.2 Mbit/s
DC-HSPA+: UL 5.76 Mbit/s; DL 42 Mbit/s
HSPA+: UL 5.76 Mbit/s; DL 21.6 Mbit/s
WCDMA PS: UL 384 kbit/s; DL 384 kbit/s
WCDMA CS: UL 64 kbit/s; DL 64 kbit/s
EDGE: UL 236.8 kbit/s; DL 236.8 kbit/s
GPRS: UL 85.6 kbit/s; DL 85.6 kbit/s
Model AVG (mA)
BulletPlus
BulletPlus + Serial Data
BulletPlus + Ethernet
BulletPlus Peak
w/WiFi (AP)
120 170
142 180
155 195
230 305
