4.0 Configuration
Used to enable (checked) is disable (unchecked) the VPN tunnel.
Local Group Setup
Specify the method for identifying the router to establish the VPN tunnel.
The Local Security Gateway is on this router; the Remote Security
Gateway is on the other router. At least one of the routers must have either
a static IP address or a dynamic IP with server id to make a connection.
IP Only: Choose this option if this router has a static WAN IP address. The WAN IP address appears
automatically. For the Remote Security Gateway Type, an extra field appears. If you know the IP address
of the remote VPN router, choose IP Address, and then enter the address.
IP + Server ID: Choose this option if this router has a static WAN IP address and a server id. The WAN IP
address appears automatically. For the Remote Security Gateway Type, an extra field appears. If you
know the IP address of the remote VPN router, choose IP Address, and then enter the address.
Dynamic IP + Server ID: Choose this option if this router has a dynamic IP address and a server id
(available such as @microhard.vpn). Enter the server id to use for authentication. The server id can be
used only for one tunnel connection.
Displays the IP address of the BulletPlus, which is the local VPN Gateway.
This option appears when the Local Security Gateway Type specifies that
the Server ID is required for the connection. The Server ID must be in the
format @name, where name can be anything. Both routers must know
each others names to establish a connection.
Next-hop Gateway means the next-hop gateway IP address for the local or
remote gateway participant's connection to the public network.
Define the local network by specifying the local subnet. The local and
remote routers must use different subnets.
© Microhard Systems Inc.
Values (checkbox)
Enable (Checked)
Local Security Gateway Type
Values (selection)
IP Only
IP + Server ID
Dynamic IP + Server ID
Interface IP Address
Values (IP Address)
Current IP Address
Values (characters)
(no default)
Next-hop Gateway IP
Values (IP Address)
(no default)
Group Subnet IP
Values (IP Address)
(no default)
Enable
Server ID
