4.0 Configuration
This selection determines if the BulletPlus will obtain an IP address
from a DHCP server on the attached network, or if a static IP address
will be entered. If a Static IP Address is chosen, the fields that follow
must also be populated.
The factory default
network settings:
IP: 192.168.168.1
Subnet: 255.255.255.0
Gateway: 192.168.168.1
If 'Static' Connection Type is selected, a valid IPv4 Address for the
network being used must be entered in the field. If 'DHCP' is chosen
this field will not appear and it will be populated automatically from the
DHCP server.
If 'Static' Connection Type is selected, the Network Mask must be
A SUBNET MASK is a bit
mask that separates the entered for the Network. If 'DHCP' is chosen this field will not appear
network and host (device)
and it will be populated automatically from the DHCP server.
portions of an IP address.
The 'unmasked' portion
leaves available the
information required to
identify the various devices
on the subnet.
If the Connection Type is set to DHCP, you can use Auto for the DNS
Mode and a DNS server will automatically be defined. If the connection
type is set as static, DNS servers can be manually specified.
Set the primary and alternate DNS (Domain Name Server) for use by
Within any IP network, each
devices on the LAN port, if required.
device must have its own
unique IP address.
© Microhard Systems Inc.
Connection Type
Values (selection)
DHCP
Static
IP Address
Values (IP Address)
192.168.168.1
Values (IP Address)
255.255.255.0
Values (selection)
Auto
Manual
Primary DNS / Secondary DNS
Values (selection)
Auto
Manual
Netmask
DNS Mode
