4.0 Configuration
Radio1 Virtual Interface
The bottom section of the Wireless Configuration provides for the configuration of the Operating Mode of
the Wireless Interface, the TX power, Wireless Network information, and Wireless Encryption. The
BulletPlus can support multiple virtual interfaces. These interfaces provide different SSID's for different
users, and can also be assigned to separate subnets (Network Interfaces) to prevent groups from
interacting.
Choose between LAN or WAN for the Virtual Interface. If additional
Network Interfaces have been defined in the Network > LAN section,
the Interface name will also appear here.
Access Point
connection to many clients, such as stations, repeaters, or other
supported wireless devices such as laptops etc.
If more than 1 Virtual Interface (more than 1 SSID) has been defined,
the BulletPlus can ONLY operate as a Access Point, and will be
locked into this mode.
Station/Client
Repeater
© Microhard Systems Inc.
Image 4-4-3: Wireless > Radio Configuration
- An Access Point may provide a wireless data
- A Station may sustain one wireless connection, i.e. to an Access Point.
- A Repeater can be connected to an Access Point to extend the range and provide a
wireless data connection to many clients, such as stations.
Network
Values (selection)
LAN
WAN
Etc..
(Additional Interfaces...)
Mode
Values (selection)
Access Point
Client
Repeater
