4.0 Configuration

4.11.4 Applications > Event Report
4.11.4.1 Event Report > Configuration
Event Reporting allows the BulletPlus to send periodic updates via UDP packets. These packets are
customizable and can be sent to up to 3 different hosts, and at a programmable interval. The event packet
can report information about the modem such as the hardware/ software versions, core temperature,
supply voltage, etc; carrier info such as signal strength (RSSI), phone number, RF Band; or about the WAN
such as if the assigned IP Address changes. All events are reported in binary.
This box allows the selection of the type of event to be reported. The
default is disabled. If Modem_event is selected, additional options appear
to the right and allow for customization of the event reported via Messages.
If Management is selected, additional check boxes appear below to select
the interfaces to report to the Microhard NMS system.
Enter the IP Address of a reachable host to send the UDP packets
© Microhard Systems Inc.
Image 4-11-6: Applications > Event Report
Event Type
Values (selection)
Modem_Event
SDP_Event
Management
Remote IP
Values (IP Address)
0.0.0.0
