Microhard Systems BulletPlus Operating Manual page 75

4.0 Configuration
All devices connecting to the BulletPlus in a given network must use
the SSID of the BulletPlus. This unique network address is not only a
security feature for a particular network, but also allows other networks
- with their own unique network address - to operate in the same
SSID: Service Set Identifier.
area without the possibility of undesired data exchange between
The 'name' of a wireless
networks.
network. In an open wireless
network, the SSID is
broadcast; in a closed system
it is not. The SSID must be
known by a potential client for
it to be able to access the
The encryption types defines the type of security used for the Wireless
wireless network.
Interface, to join a network a device must know the correct password/
passphrase/key.
Security options are dependent on the version type. This section
describes all available options. Export versions may not have all
optional available to meet regulatory requirements set government
policies.
Change the default value for
the Network Name to
something unique for your
network. Do this for an
added measure of security
and to differentiate your
This is the password, or preshared key that is required by any device
network from others which
to connect to the wireless interface of the BulletPlus. It is strongly
may be operating nearby.
recommended to always have a password defined, and changed from
the factory default.
Check this box to show the currently configured password for WPA/
WPA2 encryption passphrase.
If using Enterprise (RADIUS) encryption, enter the IP Address of the
RADIUS authentication server here.
If using Enterprise (RADIUS) encryption, enter the port number of the
RADIUS authentication server here.
This is the password, or preshared key that is required by any device
to connect to the wireless interface of the BulletPlus. It is strongly
recommended to always have a password defined, and changed from
the factory default.
© Microhard Systems Inc.
SSID
Values (string)
BulletPlus
Encryption Type
Values (selection)
Disabled
WPA (PSK)
WPA2 (PSK)
WPA+WPA2 (PSK)
WPA Enterprise (RADIUS)
WPA2 Enterprise (RADIUS)
WPA+WPA2 Enterprise(RADIUS)
WPA PSK
Values (string)
0123456789
Show Password
Values (selection)
unchecked
RADIUS IP Address
Values (IP Address)
(no default)
RADIUS Port
Values (port)
(no default)
RADIUS Server Key
Values (selection)
0123456789
75
