4.0 Configuration
4.2.9 Network > Bandwidth
The BulletPlus features Bandwidth Throttling, which allows the upload/download of connected networks/
users data speeds to be limited to a specified value. Network Bandwidth Throttling can be implemented by
each physical Ethernet interface as seen in the image below.
The rule name is used as a reference to be able to help identify which
interface or network is attached to the affected network interface.
Select the physical interface to be affected by the Bandwidth Throttling
as defined below.
Enable or disable uploading on the specified interface. This prevent
data from being uploaded to a server. (i.e uploading/sending videos or
other files to a server).
Set the data limit (speed) for file uploads if uploads have been allowed
using the Upload Bandwidth Enable.
© Microhard Systems Inc.
Image 4-2-12: Network > Bandwidth Throttling
Rule Name
Values (chars)
rule1
Network
Values (selection)
(varies)
Upload Bandwidth Enable
Values (selection)
Enable / Disable
Upload Bandwidth
Values (kbps)
10000
