4.0 Configuration
4.11.4.3 Event Report > Message Payload
Modem info:
Carrier info:
WAN Info:
Message Order:
Messages will be ordered by message type number.
For example,
If message type mask = 0x15, the eurd package will be equipped by header+modem information+carrier
information+wanip information.
If message type mask = 0x4, the eurd package will be equipped by header+carrier information.
If message type mask = 0x11, the eurd package will be equipped by header+modem infomation+wanip
infomation.
a fixed message tail
© Microhard Systems Inc.
Content length
Modem name
Hardware version
Software version
Core temperature
Supply voltage
Local IP Address
Local IP Mask
Content length
RSSI
RF Band
3G_Network
Service type
Channel number
SIM card number
Phone number
Content length
IP address
DNS1
DNS2
content length --- 2 BYTES(UINT16_T)
product name --- STRING(1—64 bytes)
image name --- STRING(1—64 bytes)
domain name --- STRING(1—64 bytes)
domain password --- STRING(32 bytes)
module list --- 5 BYTES
- 2 BYTES (UINT16_T)
- STRING (1-30 bytes)
- STRING (1-30 bytes)
- STRING (1-30 bytes)
- STRING (1-30 bytes)
- STRING (1-30 bytes)
- 4 BYTES (UINT32_T)
- 4 BYTES (UINT32_T)
- 2 BYTES (UINT16_T)
- 1 BYTE (UINT8_T)
- 2 BYTES (UINT16_T)
- STRING (1-30 Bytes)
- STRING (1-30 Bytes)
- STRING (1-30 Bytes)
- STRING (1-30 Bytes)
- STRING (1-30 Bytes)
- 2 BYTES (UINT16_T)
- 4 BYTES (UINT32_T)
- 4 BYTES (UINT32_T)
- 4 BYTES (UINT32_T)
// MD5 encryption
// radio, ethernet, carrier, usb, com
