3.0 Hardware Features
3.1.2 BulletPlus Mounting Bracket (Order Option)
© Microhard Systems Inc.
Drawing 3-4: BulletPlus Top View Dimensions (Shown with removable TS35 DIN Rail Mount)
12.6
55.2
57.2
12.6
Drawing 3-5: BulletPlus Mounting Bracket Dimensions
13.0
16.1
16.0
12.5
32.0
3.2
12.5
16.1
32.0
58.0
62.4
Note: All dimension units: Millimeter
4.0
15.2
16.8
4.0
19
